Gelenkteller mit Schwingungsdämpfung

Produktinfo

Material
- Steel version: pressure foot in tempered steel; ball element in case-hardened free-cutting steel - Stainless steel version: pressure foot and ball element in stainless steel Damper plate PUR elastomere (Sylomer V12)

Yta
- Steel version: pressure foot black oxide finish; ball element case-hardened, black oxide finish - Stainless steel version: natural finish Damper plate PUR elastomere, grey, fixed, cannot slip; range of use from -30 °C to +70 °C

Notera
The manageable load given in the table is a recommendation of the permanent static load up to which the absorption unit should be used. This static load corresponds to a pressure per area of 0.4 N/mm², at which the material reaches its optimum absorption properties. Here it is taken into account that under dynamic demands an additional load, up to 0.6 N/mm² may occur. The damper plate absorbs vibrations and prevents slipping of the Swivel Foot. Swivel Foot (without vibration absorption) see 07144.
